tube furnace

Model：PT-1200T

Description：vacuum tube furnaces is widely used in synthesis of the new material and quick sintering of the workpiece, such as, Piezoelectric ceramics, superconducting materials, magnetic materials dec.

Inquire Now

Introduction:

Features of vacuum tube furnace :
1. Operation Temperature: 1100℃ ( 1200℃ for short time).
2. Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation.
3. Heavy duty double layer structure with cooling fan. Lower temperature in outside case.
4. PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier).
5. Power control with 30 segments programmable.

We have a wide range of different optional function furnace to meet different heating requirement, also we accept customer design furnace R&D working, please email us your specific requirement, we will recommend most reasonable choice for you, thanks!

Descriptions of vacuum tube furnace :

Chamber Size	Φ50x300mm (2.0"x12")
Working Temperature	1100℃ (continuous)
Maximum Temperature	1200℃
Temperature Control	30 steps programmable and PID automatic control
Heating Rate	0~15℃/min (suggestion: ≤10℃)
Temperature Accuracy	+/-1℃
Heating Element	Fe-Cr-Al resistance wire
Working Voltage	AC 220V, Single Phase, 60/50 Hz (or according to your requirement)
Max. Power	2.5 KW
Net Weight	30 Kg

Note: there are different chamber sizes for your choice.

Related tube furnaces :

Transaction process

After-sales Service

1.We provide one year warranty for our equipment (Except the quick-wear part),Equipment damage or malfunction during the guarantee period due to equipment quality reasons, all be free maintenance.After the warranty expires, still offer lifetime and high quality service.

2.In case of failure in the process of equipment used, our company will make a deal as soon as possible, to ensure the normal operation of equipment.

3.Our company provide free equipment operation training and simple troubleshooting and maintenance training.

4.My company's technical staff can provide door-to-door service (product installation, debugging, maintenance, technical advice and instructions, etc.).

5.Our company provides transport services, packaging are carried out in accordance with the safety standard packing.Random complete technical data (user manual, maintenance manuals, relevant materials and accessories, random tools, etc.).

6.All the equipment has the CE certificate.
