Split tube furnace (1-5 heat zone)

Model£ºPT-1200T

Description£ºSplit tube furnace (1-5 heat zone) is suitable for lab experiments, such as, nano material, chemical analysis, component test, metal sintering etc. According to the concrete requirement, the furnace can be equipped with, gas mixer, flow meter and vacuum system.

Inquire Now

1.Features of Split tube furnace

(1).1200C Sliding tube furnace is using resistance wire as heating elements.
(2).Double shell casing with three cooling fans.
(3).High purity Alumina fibrous insulation for max. energy saving.
(4).Faster cooling and easy operation.


We have a wide range of different optional function furnace to meet different heating requirement, also we accept customer design furnace R&D working, please email us your specific requirement, we will recommend most reasonable choice for you, thanks!

2.Technical parameters of Split tube furnace


Model PT-1200T Split tube furnace
Limting temperature 1200¡æ
Usable range 1150¡æ
Heating rate suggestion 0-20¡æ/min
Temperature zone single
Temperature accuracy ±1¡æ
Chamber size and material OD: 25mm (or 50mm); ID: 20mm (or 44mm); Length: 610mm, Quartz tube (included)
Heated length 200mm
Heating element Resistance Wire
Thermal couple k type
Rated power 1.2KW
Working voltage AC  110-480V 50/60HZ
Temperature control PID automatic control via SCR power control
Heating curves 30 steps programmable
Preset curve 1
Chamber materials alumina fiber
Constant Heating Zone 100mm
Warranty 12 month (exclusive wearing part)

Split tube furnace can be customized according to customers’requirements.

3.Applications of Split tube furnace

Split tube furnace is suitable for lab experiments, such as, nano material, chemical analysis, component test, metal sintering etc. According to the concrete requirement, the furnace can be equipped with, gas mixer, flow meter and vacuum system.


 Transaction process


  After-sales Service


1.We provide one year warranty for our equipment (Except the quick-wear part),Equipment damage or malfunction during the guarantee period due to equipment quality reasons, all be free maintenance.After the warranty expires, still offer lifetime and high quality service.

2.In case of failure in the process of equipment used, our company will make a deal as soon as possible, to ensure the normal operation of equipment.

3.Our company provide free equipment operation training and simple troubleshooting and maintenance training.

4.My company's technical staff can provide door-to-door service (product installation, debugging, maintenance, technical advice and instructions, etc.).

5.Our company provides transport services, packaging are carried out in accordance with the safety standard packing.Random complete technical data (user manual, maintenance manuals, relevant materials and accessories, random tools, etc.).

6.All the equipment has the CE certificate.
