Multi station tubular furnace
Large Multi station tubular furnace
Model£ºPT-1600T
Description£ºMulti station tubular furnace in the horizontal or vertical, and other work stations to meet the needs of different experiments, greatly improving its use.it can be passed the vacuum atmosphere.
(1). Operation Temperature: 1600¡æ (1700¡æ for short time).
(2). Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina
fiber ceramic insulation.
(3). Heavy duty double layer structure. Lower teperature in outside case.
(4). PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier).
(5). Power control with 30 segments programmable.
(6). Can be rotated in 360° according to your requirement.
We have a wide range of different optional function furnace to meet different heating requirement, also we accept customer design furnace R&D working, please email us your specific requirement, we will recommend most reasonable choice for you, thanks!
2.Descriptions of Multi station tubular furnace :
|
Chamber Size
|
Ø60x300mm (2.5"x12")
|
|
Working Temperature
|
1500¡æ (continuous)
|
|
Maximum Temperature
|
1700¡æ (for short time)
|
|
Temperature Control
|
30 steps programmable and PID automatic control
|
|
Heating Rate
|
0~15¡æ/min (suggestion: ≤10¡æ)
|
|
Temperature Accuracy
|
+/-1¡æ
|
|
Heating Element
|
MoSi2 rod |
| Work station | Can be rotated in 360° |
|
Working Voltage
|
AC 220V, Single Phase, 60/50 Hz (or according to your requirement)
|
|
Max. Power
|
2 KW
|
|
Net Weight
|
30 Kg
|
Transaction process
After-sales Service
1.We provide one year warranty for our equipment (Except the quick-wear part),Equipment damage or malfunction during the guarantee period due to equipment quality reasons, all be free maintenance.After the warranty expires, still offer lifetime and high quality service.
2.In case of failure in the process of equipment used, our company will make a deal as soon as possible, to ensure the normal operation of equipment.
3.Our company provide free equipment operation training and simple troubleshooting and maintenance training.
4.My company's technical staff can provide door-to-door service (product installation, debugging, maintenance, technical advice and instructions, etc.).
5.Our company provides transport services, packaging are carried out in accordance with the safety standard packing.Random complete technical data (user manual, maintenance manuals, relevant materials and accessories, random tools, etc.).
6.All the equipment has the CE certificate.
